Sungrow 125CX P2

Commercial On-Grid Inverters

Input (DC) -
Recommended max. PV input power - 175 kW
Max. PV input voltage - 1100 V
Min. PV input voltage / Startup input voltage -180 V / 200 V
Rated PV input voltage - 600 V
MPP voltage range - 180 – 1000 V
No. of independent MPP inputs - 12
No. of PV strings per MPPT - 2
Max. PV input current - 360 A (30 A *12)
Max. DC short-circuit current - 480 A (40 A * 12)
Max. current for DC connector - 20A

Output (AC)
Max. AC Output power - 125 kVA
Rated AC output apparent power - 125 kVA
Max. AC output current - 181.1 A
Rated AC output current(at 230V) - 181.1 A
Rated AC voltage - 3 / N / PE, 230 / 400 V
AC voltage range - 320 – 480V
Rated grid frequency - 50 Hz / 60 Hz
Grid frequency range - 45 – 55 Hz / 55 – 65 Hz

 EFFICIENCY
Max. efficiency / European efficiency - 98.5% / 98.3%
